ProSource LR-018-PS Door Hinge, 2-1/2 in W Door Leaf, 2-1/2 in H Door Leaf, 2.2 mm Thick Door Leaf, Steel, Plain Steel
- Class: Residential
- Dimensions: 2-1/2 L x 2-1/2 W in
- Door Leaf Height: 2-1/2 in
- Door Leaf Thickness: 2.2 mm
- Door Leaf Width: 2-1/2 in
- Model #: LR-018-PS
- UPC #: 045734647121
- SKU: 2828747
Your shopping list will be used for pickup in-store
Product Details
Blank door hinge is used for interior and exterior applications. Plain steel hinges are not swaged, no holes, for weld-on applications.Key Features
- Hinges have 5 knuckles
- For cabinet and lightweight doors
- Made of steel
Item Specifications
| Class | Residential |
|---|---|
| Dimensions | 2-1/2 L x 2-1/2 W in |
| Door Leaf Height | 2-1/2 in |
| Door Leaf Thickness | 2.2 mm |
| Door Leaf Width | 2-1/2 in |
| Finish | Plain Steel |
| Knuckle Diameter | 5.3 mm |
| Knuckle Length | 66 mm |
|---|---|
| Material | Steel |
| Mounting Type | Welding |
| Orientation Type | Interior |
| Pin Diameter | 5.3 mm |
| Pin Type | Loose |
| Weight Capacity | 85 lb |
MORE DETAILS:
- ProSource_2828747_Specification_Sheet.pdf
- Application: For use on cabinets and light-weight doors
